10.22 22/210 T
- Product code
- Working pressure (bar)
- Max pressure (bar)
- Flow rate (l/h)
- Max flow rate (l/h)
- Absorbed power (kW)
- Power supply
- Pump type/RPM
- Motor thermal power
- Max inlet temperature (°C)
- 36020-00044
- 30÷200
- 210.0
- 490÷1260
- 1260.0
- 8.5
- 400-50
- RW / 1400
- 7.4
- 85.0
- High-pressure hose (m)
- Machine dimensions (cm)
- Folded handle dimensions
- Weight (kg)
- Packaging dimensions (cm)
- Quantity per pallet
- Pallet dimensions
- Units per 20-ft container
- Units per 40-ft container
- 10.0
- 85x58x105
- 85x58x70
- 75.0
- 86 x 67 x 80
- 1.0
- 86 x 67 x 80
- 32
- 68
10.22 22/210 T
- Heavy duty structure with stainless steel cover.
- Easy maintenance of motorpump and electronic panel by simply removing of the cover.
- Big pneumatic wheels (ø 300 mm); easy to handle also up and down steps and over uneven grounds.
- Stabilizing rubber feet.
- Readily serviceable brass suction filter.
- Ejector kit for low-pressure detergent suction (excludable).
- 5 litres detergent tank fitted with filter.
- Self priming RW Premium pump with oil sight glass, with level visible from the outside and brass pump head.
- Hot water seals and professional unloader valve.
- 4-pole motor (1400 rpm), well oversized and protected with paint.
- Exclusive motorpump coupling system for intensive use (9.
- 15 - 9.
- 21 models).
- Elastic coupling (10.
- 15, 10.
- 17, 10.
- 22 and 10.
- 28 models).
- Delayed TotalStop.
- Control panel with contactor and thermal protection.
- On/off rotary switch.
- Led micro-leaks detector with automatic stop system.
- Alert ordinary pump maintenance device.
- 15 mt hose reel kit (on request).
