Extra 5.12 12/180 T
- Product code
- Working pressure (bar)
- Max pressure (bar)
- Flow rate (l/h)
- Max flow rate (l/h)
- Absorbed power (kW)
- Power supply
- Pump type/RPM
- Motor thermal power
- Max inlet temperature (°C)
- Max outlet temperature (°C)
- 36030-00043
- 30÷170
- 180.0
- 300÷720
- 720.0
- 4.8
- 400-50
- AXR / 2800
- 3.7
- 60.0
- 110
- Boiler fuel tank
- Boiler fuel consumption
- Detergent tank (l)
- High-pressure hose (m)
- Machine dimensions (cm)
- Weight (kg)
- Packaging dimensions (cm)
- Quantity per pallet
- Pallet dimensions
- Units per 20-ft container
- Units per 40-ft container
- 15.0
- 3.11
- 3.5
- 15.0
- 104x62x84
- 105.0
- 100 x 65 x 100
- 1.0
- 100 x 65 x 100
- 36
- 72
Extra 5.12 12/180 T
- 15-litres capacity fuel tank with level float and fill up filter.
- Regulated low-pressure detergent suction.
- 2 poles (2800 rpm) motor with thermal protection.
- Delayed Total Stop (on JUPITER 5.
- 12T model).
- EASY START on single phase models.
- Safety valve for boiler protection.
- Boiler thermal protection.
- Rotary On-Off switch.
- Temperature setting thermostat.
- Amperometric control (on three-phase models).
- Motor rotating control (on three-phase models).
- Phase control” indicator (on three-phase models).
- “No fuel” indicator.
- Gun with pressure regulator (optional).
